Built-in inverter transformer for DC/ AC galvanic protection of industrial type loads
Full IGBT technology and electronic PFC, ensuring 0.99 input PF and THDi<3% for maximum upstream sources compatibility
Front access to all critical components for easy maintenance
Hot connection/disconnection of parallel units for easy system resizing
Accurate battery management providing ripple current minimization charge current / voltage control as per batteries manufacturers’ specifications and automatic / manual battery test for maximum battery expected life preservation
Dynamic Charging Mode (DCM) for maximum versatility in long autonomy and low charging time applications
Smart parallel management in load sharing, load synchronization of single UPS sytems and load synchronization of two paralleled systems for optimum protection
Dual DSP plus microcontroller logics for top performance and reliability
CAN-bus based distributed parallel control ensuring high load sharing accuracy and no single point of failure in parallel systems
Comprehensive set of communication options for total remote monitoring of equipment operation
Fully compliant with all international product standards for maximum quality guarantee
آیتم های اختیاری
Battery fuse switch wall-mounted box
Associated battery cabinets for long autonomy times
Parallel redundant up to 6 units or system redundancy
Load-sync option
Top cable entry
Backfeed protection bypass contactor
Bypass isolation transformer Transformers/autotransformers
for voltage adjustment
Battery voltage temperature compensation
External maintenance bypass wall mounted box
Dynamic Charging Mode (DCM)
The battery charging current can be set above the nominal, up to the DCM limit, in order to manage high capacity battery packs. The extra charging power is fed to the battery, as long as the load does not requires it. This is a firmware enabled feature
